BIOS SkyBlue™ Circadian Lighting Technology Solutions:
BIOS Biological
Static
BIOS Biological
Tunable
BIOS Biological
Dynamic
BIOS Biological
Static Circadian Lighting
Features the BIOS SkyBlue™ (490nm) for improved daytime circadian impact.
Applications: Daytime occupied spaces: 7am - 7pm
- K-12 schools
- Offices
- Daytime adult care facilities
- Medical offices
CCT Offerings
- 3000K
- 3500K
- 4000K
Lighting Controls
- On/off switch
- 0-10V
- DMX
- Wireless
- DALI
- Lutron
BIOS Biological
Tunable Circadian Lighting
Features the BIOS SkyBlue™ (490nm) high melanopic EDI with independently tunable intensity and spectrum (2 channel system) to meet daytime and evening circadian needs.
Applications: Spaces in operation overnight, after 7pm and before 7am where people do not sleep there.
- Offices
- Shiftwork
- Hospitals
- Long Term Care
- Hospitality
- Residential
- Sports Facilities
- Higher Education
CCT Offerings
- 3000K (dim to 2700K evening spectrum)
- 3500K (dim to 2700K evening spectrum)
- 4000K (dim to 2700K evening spectrum)
Lighting Controls
- Two channel control: intensity and spectrum are controlled independently.
- Does not use a BIOS Bio-Dimming™ Module
- Uses: standard 2-channel LED drivers and standard dimming interfaces/protocols (0-10V, DMX, Wireless, DALI, Lutron).
- Single-channel control: BIOS Biological Tunable Light Engines must be paired with the BIOS Bio-Dimming™ Module
- Allows intensity and spectrum to be controlled together.
BIOS Biological
Dynamic Circadian Lighting
Features the BIOS SkyBlue™ (490nm) high melanopic EDI with independently tunable intensity and spectrum with a minimal 500K shift to remove the sky blue wavelength in evening settings.
Applications: Spaces in operation overnight, after 7pm and before 7am
- Offices
- Shiftwork
- 24-hour spaces
- Long Term Care
- Hospitality
- Residential
- Sports Facilities
- Higher Education
CCT Offerings
- 3000K (dim to 2700K spectrum)
- 3500K (dim to 3000K spectrum)
- 4000K (dim to 3500K spectrum)
Lighting Controls
- On/off switch
- 0-10V
- DMX
- Wireless
- DALI
- Lutron
- Bio-Dimming™ Module*
BIOS Bio-Dimming™ Module
Designed to transition from daytime to evening. Simply dim the lights in the evening to remove the daytime sky blue wavelengths (490nm) and convert your lights from day mode to evening mode.
